Chrysler Crossfire 2004-2008 2DR Vertical Lambo Doors

Name: Chrysler Crossfire 2004-2008 2DR Vertical Lambo Doors
Brand: Vertical Doors, Inc.
SKU: VDCCRYCROS0408
Price: 1676.00 USD
Availability: InStock

Made in the USA by Vertical Doors, Inc.Part # VDCCRYCROS0408

$1,676 $2,176 Made to order

Made to order by Vertical Doors, Inc.: ships in 10–15 business days, then 3–5 days by FedEx Ground in the US.

Fits Chrysler Crossfire 2004–2008. Check yours:

Total · free US shipping

$1,676

or pay with

Kits for more than one car?

Each kit fits one car model. Add this one, then your next car’s; pay once for all.

// About this kit

Part number: VDCCRYCROS0408
Fits: Chrysler Crossfire2004–2008
Made by: Vertical Doors, Inc., USA
In the kit: Left and right hinge assemblies, gas shocks, mounting hardware, instructions

Part number VDCCRYCROS0408 comes from Vertical Doors, Inc., the only manufacturer of vertical lambo door and ZLR conversions based in the USA. The kit is built specifically for the 2004-2008 Chrysler Crossfire 2DR and fits every trim level across the 2004, 2005, 2006, 2007, and 2008 model years. The hinges are made in the USA from domestic hardened steel, and the design is patented here as well.

2 Vertical Doors, Inc. lambo door hinges, one for each side of the car
2 gas shocks to support the doors in the raised position
All mounting hardware needed to complete the conversion

Each hinge bolts directly to the Crossfire’s factory bolt pattern, and the conversion is fully reversible, so the car can be returned to its stock doors down the road. One fitment note to plan for: the factory windshield washer reservoir must be modified or replaced with a smaller aftermarket reservoir to run this kit. An instruction manual is supplied in the box and VDI offers free tech support, but we recommend having a professional installer do the job while following those supplied instructions.

// The part you’re buying

Drag to turn it, Space to open the door, Z to zoom on the hinge, X to take it apart.

Shown: a typical VDI kit. Your kit is made for your car, so its exact plate, arm, brackets and shock differ from this drawing.

The kit you buy: mounting plate, pin and hub, swing arm, door bracket, gas shock, cam stop, boltsYour car: the body apron and the doorThe factory hinge it replacesThe kit starts as its separate pieces, then goes together in the order it's fitted. The door first swings out on the vertical pin, then lifts on the round bearing hub, and the gas shock holds it up: the two-stage motion in VDI's patent (US 6,845,547). Each kit has right and left hinge assemblies, two gas shocks, M8 bolts with washers, shoulder bolts and pins (VDI install manuals); set screw #2 and nut #1 adjust where the door closes. A typical kit, drawn from VDI's Crossfire manual: the plate, arm, brackets, shock and angles differ by vehicle, and each kit is made for its car.
