Ford Mustang 2005-2010 Vertical Lambo Doors

Name: Ford Mustang 2005-2010 Vertical Lambo Doors
Brand: Vertical Doors, Inc.
SKU: VDCFM0510
Price: 1099.00 USD
Availability: InStock

Made in the USA by Vertical Doors, Inc.Part # VDCFM0510

$1,099 $1,499 Made to order

Made to order by Vertical Doors, Inc.: ships in 10–15 business days, then 3–5 days by FedEx Ground in the US.

Fits Ford Mustang 2005–2010. Check yours:

Total · free US shipping

$1,099

or pay with

Kits for more than one car?

Each kit fits one car model. Add this one, then your next car’s; pay once for all.

// About this kit

Part number: VDCFM0510
Fits: Ford Mustang2005–2010
Made by: Vertical Doors, Inc., USA
In the kit: Left and right hinge assemblies, gas shocks, mounting hardware, instructions

Mechanically, this kit is a hinge swap. Part number VDCFM0510 from Vertical Doors, Inc. replaces the stock hinges on your Mustang with hinge assemblies that swing the door out and then straight up, with a gas shock on each side to carry the door’s weight through its travel. The whole thing bolts to the factory bolt pattern on the body and the door, which keeps the job straightforward and keeps your car intact.

In the box:

2 Vertical Doors, Inc. lambo door hinges, one for each side
2 gas shocks
All mounting hardware

Fitment covers the 2005, 2006, 2007, 2008, 2009 and 2010 Ford Mustang in every trim. The hinges are built in the USA from domestic hardened steel, and the design is patented here too. Because it bolts to existing mounting points, the conversion is completely reversible: put the factory hinges back on and the car returns to stock. Each kit ships with a step-by-step instruction manual and VDI offers free tech support, but we recommend having a professional installer do the work using the instructions supplied with the kit.

// The part you’re buying

Drag to turn it, Space to open the door, Z to zoom on the hinge, X to take it apart.

Shown: a typical VDI kit. Your kit is made for your car, so its exact plate, arm, brackets and shock differ from this drawing.

The kit you buy: mounting plate, pin and hub, swing arm, door bracket, gas shock, cam stop, boltsYour car: the body apron and the doorThe factory hinge it replacesThe kit starts as its separate pieces, then goes together in the order it's fitted. The door first swings out on the vertical pin, then lifts on the round bearing hub, and the gas shock holds it up: the two-stage motion in VDI's patent (US 6,845,547). Each kit has right and left hinge assemblies, two gas shocks, M8 bolts with washers, shoulder bolts and pins (VDI install manuals); set screw #2 and nut #1 adjust where the door closes. A typical kit, drawn from VDI's Crossfire manual: the plate, arm, brackets, shock and angles differ by vehicle, and each kit is made for its car.
