Vertical Doors, Inc. sells this kit as final sale: it can’t be returned or exchanged, so check your year and model before ordering. Returns policy

Questions about fit? Email sales@verticallambodoors.com.

Chevrolet · Full Size Truck 99-06

Chevrolet Full Size Truck 1999-2006 Vertical Lambo Doors

Name: Chevrolet Full Size Truck 1999-2006 Vertical Lambo Doors
Brand: Vertical Doors, Inc.
SKU: VDCCHEVY-GMC9906
Price: 1099.00 USD
Availability: InStock

Made in the USA by Vertical Doors, Inc.Part # VDCCHEVY-GMC9906

$1,099 $1,499 Made to order

Made to order by Vertical Doors, Inc.: ships in 10–15 business days, then 3–5 days by FedEx Ground in the US.

Fits Chevrolet Full Size Truck 1999–2006. Check yours:

Total · free US shipping

$1,099

or pay with

Kits for more than one car?

Each kit fits one car model. Add this one, then your next car’s; pay once for all.

// About this kit

Part number: VDCCHEVY-GMC9906
Fits: Chevrolet Full Size Truck1999–2006
Made by: Vertical Doors, Inc., USA
In the kit: Left and right hinge assemblies, gas shocks, mounting hardware, instructions

The 1999-2006 Chevrolet full size truck is a big, square-shouldered platform, and swinging the doors up instead of out changes the whole stance of the build. This vertical door conversion kit, part number VDCCHEVY-GMC9906, comes from Vertical Doors, Inc. and covers every trim of the full size truck from 1999 through 2006.

Each kit includes:

2 Vertical Doors, Inc. lambo door hinges, one for each side
2 gas shocks to hold the doors up and control the swing
All the mounting hardware needed for the job

The hinges are built to line up with the factory bolt pattern, but GM trucks through 2006 left the factory with welded-on door hinges, so plan on some drilling and tapping during the install. The conversion is reversible, so the truck can go back to stock doors down the road. Every kit is made in the USA from domestic hardened steel and the design is patented here as well. An instruction manual ships with the kit, and we recommend having a professional installer work through it rather than making this your first wrenching project. Keep in mind that truck and SUV kits are non-refundable and non-exchangeable, so confirm your application before ordering.

// The part you’re buying

Drag to turn it, Space to open the door, Z to zoom on the hinge, X to take it apart.

Shown: a typical VDI kit. Your kit is made for your car, so its exact plate, arm, brackets and shock differ from this drawing.

The kit you buy: mounting plate, pin and hub, swing arm, door bracket, gas shock, cam stop, boltsYour car: the body apron and the doorThe factory hinge it replacesThe kit starts as its separate pieces, then goes together in the order it's fitted. The door first swings out on the vertical pin, then lifts on the round bearing hub, and the gas shock holds it up: the two-stage motion in VDI's patent (US 6,845,547). Each kit has right and left hinge assemblies, two gas shocks, M8 bolts with washers, shoulder bolts and pins (VDI install manuals); set screw #2 and nut #1 adjust where the door closes. A typical kit, drawn from VDI's Crossfire manual: the plate, arm, brackets, shock and angles differ by vehicle, and each kit is made for its car.
